Description
Turntable section
Type: Belt-drive
Motor: DC Motor
Rotation Speeds: 33-1/3 rpm, 45 rpm
Wow-and-Flutters: less than 0.1%
S/N Ratio: 67dB (A-weighted, 20kHz LPF)
Turntable (Platter): Die-cast aluminium, 30cm diameter
Tonearm section
Type: Static-balanced, S-shape with knife-edge bearings
Effective Length: 223mm
Anti-skating mechanism: Supported
Stylus Pressure Range: 0g to 5.0g
Compatible Cartridge Weight:
– 3.0g to 12.0g
– 14g to 23g (including Head-shell)
Cartridge sections
Type: VM-series (Moving Magnet-type)
Output Voltage: 4.0mV (1kHz, 5cm/sec.)
Stylus Pressure Range: 1.8g to 2.2g (2.0g recommended)
Cartridge Weight: 6.1g
Head-shell Weight: 11g (incl. screws, nuts, and wires)
Stylus Life: approx. 300 hours (depending on conditions)
