Description
Nominal speeds 33/45 r.p.m.. *** 78 r.p.m. optional
Speed variance 33: ±0.50% 45: ±0.60%
Wow and flutter 33: ±0.17% 45: ±0.15%
Signal to noise 68dB
Effective tonearm mass 6g
Effective tonearm length 8.6 ” ( 218.5 mm)
Overhang 18,5 mm
Power consumption 4 W/ 0 W in Stand-By
Outboard power supply 15V / 0 – 0.8 mA DC (set at 0.5 mA), universal power supply
Dimensions (W x H x D) 415 x 118 x 320 mm, dust cover open 415 x 365 x 405mm
Weight 5,6 kg
Dimensions packaging (W x H x D) 488 x 235 x 393 mm
Weight incl. packaging 8.0kg
—–
MM-Cartridge Ortofon 2M Red:
Frequency range 20-22.000Hz
Channel separation 22dB/1kHz
Output voltage 5.5mV
Recommended load impedance 47kohms/amplifier connection – MM-input
Compliance/stylus type 20µm/mN – elliptical
Recommended tracking force 17.5mN
Weight 7.2g
