Description
WEIGHT
16.9 kg (37.3 lbs.)
DIMENSION (H X W X D)
175 x 550 x 308.5 mm (6.9 x 21.7 x 12.1 in.) with terminal*
DIMENSION (H X W X D)
175 x 550 x 285 Cabinet only
DESIGN
Three-way closed Box
CROSSOVER FREQUENCIES
400Hz, 2.9kHz
FREQUENCY RANGE
64Hz-50kHz (-6dB)
TYPICAL IN-ROOM BASS RESPONSE
49Hz (-6dB)
FREQUENCY RESPONSE
74Hz-28kHz (±3dB)
HARMONIC DISTORTION
<0.3% 120Hz-20kHz (90dB, 1m)
MAXIMUM OUTPUT
110dB
AMPLIFIER POWER
15-200W (recommended)
NOMINAL IMPEDANCE
8Ohms (min.3.2Ohms)
DRIVE UNITS
Uni-Q Driver Array:
HF: 25mm (1in.) vented aluminium dome
MF: 125mm (5in.) aluminium cone
BASS DRIVER
LF: 2 x 130mm (5.25in.) hybrid aluminium
FINISHES
Black Gloss / White Gloss / Walnut
* Measurement per unit
